Fast SC Connector, Optical Fiber Fast Connector Fiber Optic Fast Connector: In the context of networking and telecommunications, a fast connector typically refers to a type of connector used to terminate or join optical fibers quickly and without the need for extensive splicing or specialized tools. These connectors are designed to make the installation and maintenance of fiber optic cables more efficient, SC/UPC Fast Connector (CC-FCSU-925T), suitable for: Ф3.0 mm & Ф2.0 mm Cable Ф0.9 invisible cable 2.0x3.0mm drop cable, Fiber Diameter: 125μm (652 & 657), Coating Diameter: 250 & 900μm, Mode: SM, Insertion Loss: ≤ 0.5dB (1310nm & 1550nm), Classic Value: 0.3dB, Return Loss: ≥50dB, Tensile Strength: >30N/2min.
Spesifikasjon
|
Punkt |
Spesifikasjon |
|
|
Kabelomfang |
Ф3.0 mm & Ф2.0 mm kabel Ф0.9 usynlig kabel 2.0x3.0mm fallkabel |
|
|
Fiberdiameter |
125μm (652 & 657) |
|
|
Beleggdiameter |
250 & 900μm |
|
|
Modus |
SM |
|
|
Driftstid |
ca. 2 minutter (ekskluder forhåndsinnstilling av fiber) |
|
|
Innsettingstap |
Mindre enn eller lik {{0}},5 dB (1310nm og 1550nm), klassisk verdi: 0,3dB |
|
|
Returner tap |
Større enn eller lik 50dB for UPC |
|
|
Strekkstyrke |
>30 N/2min |
|
|
Temperatur |
-40-+85 grad |
|
|
Strekkstyrke |
>30N/2min |
|
|
Mekanisk holdbarhet (500 ganger) |
△ IL Mindre enn eller lik 0,3 dB, △ RL＜5 dB |
|
|
Falltest (4m betonggulv, en gang i hver retning, tre ganger totalt) |
△ IL Mindre enn eller lik 0.3dB |
|
